    100mm Red Copper Pipes Continuous Casting Plant , Horizontal Casting Machine

    Ask Lasest Price
    Brand Name : JINGJIE
    Model Number : GVT
    Price : negotiation
    Payment Terms : T/T or L/C
    Supply Ability : 10sets per month
    Delivery Time : 30 working days after received your payment
    • Product Details
    • Company Profile

    100mm Red Copper Pipes Continuous Casting Plant , Horizontal Casting Machine


    name


    100mm Red Copper Pipes Continuous Casting Plant , Horizontal Casting Machine




    Equipment Components List of Horizontal Continuous Casting Production line for Rod-Wire


    No.Equipment Name and Spec.UnitQuantityRemarks
    1Melting furnaceset1Including melting groove, coil, waer jacket and iron core.
    2Chuteset2One in-use and one standby
    3Holding furnaceset1Including melting groove, coil, water jacket, iron core, vertical temperature measurement device (specially-made), thermocouple (containing platinum and rhodium) and protection tube.
    4Molten steel storage ladle and chuteset1For transferring material into the mold after sintering in holding furnace.
    5mold system (Ф30-200)set2Including graphite mold
    6Dragger (5KW)set1
    7Synchronized auto-tracking sawing machineset1
    8Material stock platformset1Chain drive, length of 5M
    9Header tankset1
    10Traction carrier rollerSet1
    11Cooling water distributorset1Including cooling water for transformer, reactor, coil of electric furnace, water jacket, water-cooling cable, and mold (primary and secondary cooling).
    12Hydraulic systemset2

    Including hydraulic station and cylinder
    (The hydraulic components produced by YUCI YUKEN HYDRAULICS CO., LTD. are adopted)

    13Electric-control operation system of electric furnaceset1Including the control cabinet for melting furnace and holding furnace (Siemens is chosen for main electrical elements).
    14Process control operation systemset1For control of servo motor and process, synchronized auto-tracking sawing machine, and control of material stock platform.

    Our Factory Main Line Of the Copper Continuous Casting Machine /Horizontal Continuous Casting Machine / Vertical Continuous Casting Machine / Billet Continuous Casting Machine / Steel Continuous Casting Machine / Slab Continuous Casting Machine / Upward Continuous Casting Machine.We Can Provide You With After Sales Service Engineer, Provide Techincal Consultation And Training For A New Factory.
