    Industrial Copper Wire Drawing Machinery Electric Touch Screen Control

    Ask Lasest Price
    Brand Name : Jingjie
    Model Number : TZJ-250
    Price : negotiation
    Payment Terms : T/T or L/C
    Supply Ability : 10sets per month
    Delivery Time : 30 working days after received your payment
    • Product Details
    • Company Profile

    Industrial Copper Wire Drawing Machinery Electric Touch Screen Control


    Industrial Copper Wire Drawing Machinery Electric Touch Screen Control​



    Main technical parameters

    1Drawing materialCopper alloy and copper rod
    2Equipment typeHorizontal arrangement, semi diffuse lubrication, each wire drawing wheel adopts independent motor
    3Motor powerYVP 3DKW*12
    4Drawing modulus13n
    5Capstan diameterΦ450mm
    6Drum form and number

    Split type
    12n

    7Drum diameterΦ450mm
    8Inlet wire diameterΦ8mm
    9Minimum outlet diameterΦ3.1mm-Φ1.2mm
    10Outlet speedΦ3.0mm 700n/min
    11Output

    Φ4.5mm (360n/min) 3000kg/h
    Φ3.0mm 2500kg/h

    12Main motor powerYVP 3DKW*12
    13Capstan motor powerYVP SOKW
    14Driving modeSynchronous toothed belt drive
    15Electric controlTouch screen and PLC control
    16Control modeFrequency control
    17Annealing voltage65V
    18Maximum annealing current5000A
    19Annealing speed300-1000m/min
    20Winder model

    SD-800 inversions
    Plum blossom fall line type

    21Winding machine power22kw-18kw
    22Other winder modelSP-630 double disc automatic changing disc type
    23Winding machine power22kw*2



    Cold drawing machine
    Main technical parameters

    TypeLW5LW8LW10LW15LW20LW30LW40LW60
    Rated drawing force50x10³80x10³100x10³150x10³200x10³300x10³400x10³600x10³
    Maximum admitted diameterΦ30Φ32Φ40Φ45Φ45Φ50Φ60Φ80
    Maximun Reducing Rale2030303030303030
    Drawing Speed10101099999
    No. Of Drawing Length24668888
    Maximun Drawing Length88101010101010
    Returning Speed of the Vehice6060606060606060
    Motor Power18.5303745557590115
    Motor Speed980980980980980740740740
    Speed Raducer TypeJZQ500JZQ650JZQ750JZQ850JZQ1000ZS1150JZQ1250JZQ1350
    Total Weight60008000110001500022000310004000045000


    Our company can perform specific designing and developing according to customers' specific requirements.
