Copper Rod D17mm-D30 Upcasting Upward Continuous Casting Machine Annnual 10000MT

This upward continuous casting line is mainly used for producing bright oxygen free copper rod, flat copper bar and copper strip.

Main Technical Parameters of Machine

a) Annual production capacity: about 10000t (When Producing copper rods under full load by using cathode copper plate)

b) Furnace structure: three-combined furnace 210KW+210KW+210KW

c) Casting rod number: 20 rods

d) Casting rod diameter: φ8mm

e) Upcasting speed: 0~2400 mm/min

f) Annual working hours: 8000 hours

g) Liquid level tracking precision: ±2mm

h) Take-up specification: φ700mm×φ1500mm

i) Coiling form: curvature automatic adjustment

j) Copper melting rate: above 1500kg/h

k) Power consumption of copper rod per ton: ~400KWH (When Producing copper rods under full load by using cathode copper plate)

Equipment Composition

Electrolytic copper plate (cathode copper/99.9% copper scraps) -- charging device (can match) - furnace system (melting furnace -- transition warehouse - holding furnace) - continuous casting machine crystallization moulding) -- dragger - speed device - automatic winding machine - for sale or deep processing

Flow Chart

Electrolytic copper plate (99.9% copper scraps) is joined in the melting furnaces through the charging device (according to the user needs),

(if the raw materials is not 1# red copper, our company can design and install the reverberatory furnace before melting furnaces to remove the copper impurity).

The copper plate through W-type inductor into liquid, then flow smoothly from the transition storehouse to the holding furnace, and then is in the steady reduction process through the surface covered with charcoal, at last is crystallized swiftly to the cast copper rod by the crystallizerof the upcast plant by upward copper rod process at the same time, cast copper rod is upward casted intermittently through the two traction roller. The cast copper rod through the hauling machine, and the wheelframe, the speed adjusting gear, then to the automatic winding machine to wind copper rod.

Main Technology Parameter For

Copper Rod D17mm-D30 Upcasting Upward Continuous Casting Machine Annnual 10000MT

PICTURES
